POMING Single Phase Relay Type Voltage Stabilizer with Ultra Low & Wide Input Voltage 65V-270V

Description

Product Description:

With relay type voltage stabilizer, POMING’s DVR65 Series voltage stabilizer can work for the ultra low voltage environment.

As no motor inside, its more slient than the motor type.

Advantages:

Undistorted waveform

Small in size

Light in weight

High in efficiency

Wide input voltage range

Technical Parameters

Technical Parameters		Model N.O.	Capacity (KVA)	Product Size (cm)	Package Size (cm)	Qty per package (pcs)	Weight(kg)
Input voltage	AC65V-270V	DVR65-5KVA	5	282520	60.53525.5	2	24.8
Output voltage	220V±8%	DVR65-8KVA	8	342427.5	433436.5	1	16.2
Phase	Simplex	DVR65-10KVA	10	342427.5	433436.5	1	19.2
Adjust the time	≤1second (input voltage change≤10%)	DVR65-12KVA	12	342427.5	433436.5	1	22.2
Efficiency	≥90%	DVR65-15KVA	15	38.52931.5	47.53940.5	1	25.7
Ambient temperature	-15℃ ~+40°℃	DVR65-20KVA	20	38.52931.5	47.53940.5	1	32.8
Relative humidity	<90%	DVR65-30KVA	30	483342	564351	1	42.6
Frequency	50Hz/60Hz
Waveform distortion	No additional waveform distortion
Insulation resistance	Under normal conditions≥2MΩ
Output overvoltage protection	1500V/1min
